Ultra-high efficiency above 96%
Next-gen high-voltage platform ready
Low total cost of ownership
Advanced safety protection features
Smart load-balancing technology
Future-proof firmware upgradeable
| Rated Input | 380Vac±15%, 50/60Hz, L1+L2+L3+N+PE | ||
| Rated Input current | 93A~738A | ||
| Output Interface | CCS1+CCS1/CCS2+CCS2/GB/T+GB/T/CHAdeMO+CHAdeMO | ||
| Output Power | 60KW/80KW/120KW/160KW/200KW/240KW/300KW/360KW/400KW/480kW max. | ||
| Output Current | 0-700A | ||
| Output Voltage | 200-1000Vdc | ||
| Power Factor | ≥0.99 (50% load above) | ||
| Efficiency | 95% @Nominal Output Power | ||
| Human-Machine Interface | |||
| Display | 12.1-inch touch screen | ||
| Operating System | Android | ||
| Language | English (customizable and switchable language) | ||
| Emergency Stop Button | Support | ||
| User Authentication | RFID Card, APP, Password, Credit Card (Optional) | ||
| RFID Reader | ISO/IEC 14443-A, Mifare one(M1) | ||
| POS | PAX IM30 (Optional) | ||
| Communication | |||
| Network Interface | Ethernet, 3G/4G, WiFi | ||
| EVSE & Backend protocol | OCPP 1.6J/OCPP 2.0.1(Optional) | ||
| EVSE&EV Protocol | DIN 70121, ISO 15118 | ||
| Machine parameters | |||
| Number of Outputs | 2 | ||
| Charging cable length | 5m | ||
| IP Rating | IP54 | ||
| Cooling | Forced Air Cooling | ||
| Case material | Galvanized Steel | ||
| Dimensions (HxWxD) | 60KW:800* 510*1800 mm | ||
| 80KW:800* 510*1800 mm | |||
| 120KW:800* 510*1800 mm | |||
| 160KW:800* 510*1800 mm | |||
| 200KW:800* 600*1800 mm | |||
| 240KW:800* 600*1800 mm | |||
| 300KW:800* 780*1800 mm | |||
| 360KW:800* 780*1800 mm | |||
| 400KW:800* 780*1800 mm | |||
| 480KW:800* 680*1927 mm | |||
| Installation | Ground Mounting | ||
| Safety Protection | Over Current, Under Voltage, Residual Current, Surge Protection, Leakage Protection, Short | ||
| Circuit, Over Temperature, etc. | |||
| Environmental Parameters | |||
| Operating Temperature | -25℃to 55℃ | ||
| Storage Temperature | -40℃to 70℃ | ||
| Humidity | 5% to 95% Without Condensation | ||
| Operating Altitude | ≤2000m | ||
| Certification and Standards | |||
| Certification | CE, RED, CB, TUV Mark | ||
| Standards and compliance | EN IEC 61851-1, EN 61851-23, EN 61851-24, EN IEC 61851-21-2,EN IEC 61000-6 | ||
