7~14KW Model C

Cost-effective AC charger with robust build quality and IP-rated weather resistance. Offers 7–14kW flexible output, suitable for both indoor and outdoor installation environments.

Highlights of Home AC Charger 7~14KW Model C

Robust build quality and durability
Affordable price with premium features
Indoor and outdoor installation ready
Low maintenance requirements
Stable and reliable power output
Universal compatibility with all EVs

Specification of Home AC Charger 7~14KW Model C

Name	7KW AC Charging Station Model C
Specifications and models	ZCG-ACC-7KW-1
Total Size (mm)	32021095mm
Power rating	7KW
Human-computer interaction	4.3-inch color touchscreen with LED indicator lights
Number of Charging Ports	1
Input voltage	220Vac±15%
Incoming frequency	50±3Hz
Output voltage	220Vac±15%
Output	32A
Flow Limit Protection Value	≥110%
Working Altitude	Altitude ≤ 2000 meters
Working temperature	-20℃～+50℃
Working Humidity	5% to 95% non-frosting
Charging Method	Card Payment / Scan Code Payment
Charging Mode	With automatic stop, fixed power, fixed charge, or fixed time
Network Connection Method	Ethernet/4G/Wi-Fi/Bluetooth
Operative norm	IEC 61851-1:2017；IEC 62196-2:2016;GB\T 20234、GB/T 18487、GB/T 27930、NB\T 33008
Charging cable length	Standard: 5 meters (optional)
Levels of protection	Ip54
Cabling Method	Enter from the bottom; exit from the bottom
Way to install	vertical
Measuring accuracy	Level 1
Residual Current Protection	Rated operating current ≤ 30 mA; rated operating time ≤ 0.1s
Noise control	≤60dB
Defencive function	Overvoltage protection, Undervoltage protection, Overload protection, Short-circuit protection, Grounding protection, Overtemperature protection, Low-temperature protection, Insulation monitoring protection, Reverse polarity protection, Lightning protection, Emergency stop protection, Earth leakage protection
MTBF	100,000 hours
Mechanical components of charging connectors life span	≥10,000 times
