Real-time energy consumption monitoring
Built-in load-balancing technology
Smart home energy system integration
Over-voltage and over-temperature protection
Sleek modern appearance design
User-friendly LED status indicators
| Name | 7KW AC Charging Station Model D |
| Specifications and models | ZCG-ACD-7KW-1 |
| Total Size (mm) | 320*210*95mm |
| Power rating | 7KW |
| Human-computer interaction | 4.3-inch color touchscreen with LED indicator lights |
| Number of Charging Ports | 1 |
| Input voltage | 220Vac±15% |
| Incoming frequency | 50±3Hz |
| Output voltage | 220Vac±15% |
| Output | 32A |
| Flow Limit Protection Value | ≥110% |
| Working Altitude | Altitude ≤ 2000 meters |
| Working temperature | -20℃～+50℃ |
| Working Humidity | 5% to 95% non-frosting |
| Charging Method | Card Payment / Scan Code Payment |
| Charging Mode | With automatic stop, fixed power, fixed charge, or fixed time |
| Network Connection Method | Ethernet/4G/Wi-Fi/Bluetooth |
| Operative norm | IEC 61851-1:2017；IEC 62196-2:2016;GB\T 20234、GB/T 18487、GB/T 27930、NB\T 33008 |
| Charging cable length | Standard: 5 meters (optional) |
| Levels of protection | Ip54 |
| Cabling Method | Enter from the bottom; exit from the bottom |
| Way to install | vertical |
| Measuring accuracy | Level 1 |
| Residual Current Protection | Rated operating current ≤ 30 mA; rated operating time ≤ 0.1s |
| Noise control | ≤60dB |
| Defencive function | Overvoltage protection, Undervoltage protection, Overload protection, Short-circuit protection, Grounding protection, Overtemperature protection, Low-temperature protection, Insulation monitoring protection, Reverse polarity protection, Lightning protection, Emergency stop protection, Earth leakage protection |
| MTBF | 100,000 hours |
| Mechanical components of charging connectors life span | ≥10,000 times |
