241kWh capacity with hybrid energy input
Supports PV, grid, and generator integration
Smart energy scheduling for cost savings
Reduces peak demand charges effectively
Versatile for diverse commercial scenarios
Advanced remote monitoring and control
| Basic Model | Model Name | ZCI241100AHY (Hybrid Inverter All-in-one ESS) |
| DC Battery Parameters | Rated Battery Energy | 241kWh |
| Rated Battery Voltage | 768V | |
| Battery Voltage Operating Range | 696V ~ 852V | |
| Battery Cell Type | LFP Lithium Iron Phosphate | |
| Battery Capacity | 314Ah | |
| Battery Cycle Life | 6,000 cycles (0.5C, 95% DOD, 80% SOH) | |
| Standard Charge/Discharge Rate | 0.5C | |
| Battery Pack Series & Parallel Connection | 1P240S | |
| Module Cooling Method | Forced Air Cooling | |
| AC PCS Converter Parameters | Rated AC Output Power | 100kW |
| Max Overload Power | 110kW | |
| Max Output Current | 160A | |
| Rated AC Voltage | 400V | |
| AC Voltage Tolerance Range | ±15% | |
| Rated AC Frequency | 50Hz / 60Hz | |
| Wiring Configuration | 3P+N+PE | |
| Current THDI (Rated Power) | less than 3% | |
| Adjustable Power Factor | ±0.99 (Capacitive / Inductive) | |
| Voltage THDU (Linear Load) | less than 3% | |
| PCS Cooling Type | Forced Air Cooling | |
| PCS Peak Conversion Efficiency | 98.50% | |
| Whole System Parameters | System Cycle Efficiency | ≥90% |
| Ingress Protection Grade | IP54 | |
| Standard Corrosion Resistance Grade | C3 (C4 / C5 optional) | |
| Fire Suppression Option | Aerosol / Perfluoroketone (Optional) | |
| Transformer Partition Type | Non-isolated (External transformer optional) | |
| Operating Relative Humidity | 0~95% (Non-condensing) | |
| Ambient Operating Temperature | -30℃ ~ +55℃ (Power derating above 45℃) | |
| Max Install Altitude | ≤3000m (Derating required above 2000m) | |
| BMS Communication Interface | CAN | |
| EMS Communication Interface | 4G / CAN / RS485 | |
| Overall Cabinet Dimension (W×D×H) | 1030 × 1350 × 2400 mm | |
| Net Weight of Whole Unit | 2.6 Tons | |
| Annual Age-related Decay Rate | less than 3% | |
| Standard Warranty Period | 5 Years | |
| Product Overview | Integrated Structure | All-in-one cabinet integrated with battery, BMS, EMS and PCS, suitable for grid-connected C&I energy storage projects |
