High energy density for compact packaging
Supports next-gen 800V fast-charging
Enhanced thermal performance air-cooling
Advanced BMS for cell balancing
Lightweight design improves vehicle range
Reliable performance under varied climates
| parameter | ||
| model | LFP51280 | LFP51314 |
| Standard Energy (Wh) | 14336 | 16076.8 |
| nominal voltage （V） | 51.2 | 51.2 |
| effective energy （WH） | 12902.4 | 14469.12 |
| Charging/Discharging Voltage (V) | 45.6-56.8 | 45.6-56.8 |
| Charging/Discharging Current (A) | 140 | 157 |
| power dissipation （W） | ≤10 | ≤10 |
| check | System voltage, Battery voltage, Battery temperature, System current, Battery level | System voltage, Battery voltage, Battery temperature, System current, Battery level |
| cooling-down method | forced air cooling | forced air cooling |
| designed life | >10 years | >10 years |
| cycle life | ≥6000@25℃ | ≥6000@25℃ |
| communication mode | RS485/CAN | RS485/CAN |
| working temperature | 0-40℃ | 0-40℃ |
| storage temperature | -20-70℃ | -20-70℃ |
| humidity | 15%-80% | 15%-80% |
| size （mm） | 885*434*238.2 | 585*434*238.2 |
| weight （Kg） | 108 | 108 |
| *Please note that product dimensions and specifications may vary; refer to the latest physical product for exact details. Compatible with brands including Deye, Atess, Megarevo, Sinexcel, Solux, Growatt, etc. | ||
