High energy density for compact packaging
Supports next-gen 800V fast-charging
Enhanced thermal performance air-cooling
Advanced BMS for cell balancing
Lightweight design improves vehicle range
Reliable performance under varied climates
| parameter | |
| model | LFP76120 |
| Standard Energy (Wh) | 9216 |
| nominal voltage （V） | 76.8 |
| effective energy （WH） | 8294.4 |
| Charging/Discharging Voltage (V) | 68.4-85.2 |
| Charging/Discharging Current (A) | 120 |
| power dissipation （W） | ≤10 |
| check | System voltage, Battery voltage, Battery temperature, System current, Battery level |
| cooling-down method | forced air cooling |
| designed life | >10 years |
| cycle life | ≥4000@25℃ |
| communication mode | RS485/CAN |
| working temperature | 0-40℃ |
| storage temperature | -20-70℃ |
| humidity | 15%-80% |
| size （mm） | 468*642*202 |
| weight （Kg） | 86 |
| *Please note that product dimensions and specifications may vary; refer to the latest physical product for exact details. Compatible with brands including Deye, Atess, Megarevo, Sinexcel, Solux, Growatt, etc. | |
