V2G 7KW /11KW

Bidirectional vehicle-to-grid charger enabling energy feedback to the grid. Available in 7kW and 11kW models, supports smart charging and peak-load management for homes and offices.

Highlights of V2G 7KW /11KW

Bidirectional energy flow technology
Supports grid peak-load management
Available in 7kW and 11kW models
Smart scheduling for cost optimization
Reduces electricity bills via V2G revenue
Compact design for home and office use

Specification of V2G 7KW /11KW

Port	Parameter	Rating

AC input	Voltage	230(187-276)	a.c.V
	Current	32.6(40max)	a.c.A
	Frequency	50/60	Hz
	Power factor	-1.6

AC output	Voltage	230(187-276)	a.c.V
	Current	30.5(37.4max)	a.c.A
	Frequency	50/60	Hz
	Power factor	-1.6

	Maximum output	40	a.c.A
	overcurrent protection
DC input	Voltage	1000(300-1000)	d.c.V
	Current	7KW:7.5(25max)	d.c.A
		11KW:16.7(32max)
DC output	Voltage	1000(200-1000)	d.c.V
	Current	7KW:7(23.3max)	d.c.A
		11KW:16.7(36.7max)
ALL ports	Protective class	ClassI

	Over voltage category	ACⅢ/DCⅡ

Inverter topology	Type	Isolated

Active anti-islanding	Method	Frequency instability
Ingress protection (IP)	Rating
rating
Temperature operating	Range	-25~+50	℃
Range		(derating above 50)
Generaldata	Storage temperature	-40~75	℃
	Relative humidity	≤95%RH,no condensation

	Cooling	Forced air cooling

	Altitude	2000m	Power derating
			above 2000m
	Dimensions	7KW:580410206(LWD)	mm
		11KW:660420207(LWD)
	Net weight	7KW:<41	kg
		11KW:46
	Noises	<55dB	Rated conditions
	Efficiency(Max)	≥94.5%

	Standby power	≤15W

	Housing material	Metal shell

	Installation	Wall mounted/floor mounted

	Cooling method	Independent air duct heat dissipation

	Startup method	RFID card (Standard)
		QR code(Optional)
	Networking mode	Bluetooth/WIFI(Standard)
		4G(Optional)/Ethernet(Optional)
	Communication interface	RS485,CAN

	Alarm mode	Sound and light alarms

	Charging standard	IEC62196(CCS2)

	Icw	8KA/10ms

	User interface	5-inch LCD,LED indicator
		RFID reader
